F13 BAR
F13 BAR is the most innovative stirrup machine to process bars completely automatically, guaranteeing maximum flexibility, productivity and quality of the finished product.
F13 BAR 3D
STOCK BAR STIRRUP MACHINE
BAR ∅8 - ∅13 mm
• Automatic bar loader
• TFS – Track Feeding System
• Zero scrap
• 3D device
Request information
F13 BAR
AUTOMATIC “STOCK-BAR” STIRRUP BENDING MACHINE
The F13 BAR is a new-generation automatic stirrup bending machine for stock bars, designed to ensure maximum flexibility, productivity, and finished product quality thanks to a fully automated process. It can process bars from 8 to 13 mm in diameter and lengths up to 18 meters, producing stirrups and shapes in 2D and 3D, including bidirectional forms, as well as straight bars or bars with multiple bends. The system allows the use of 100% of the bar length, eliminating scrap, and reduces industrial costs by minimizing the number of machines and operators required.
DIAMETER RANGE
Single bar strand ∅8 - ∅13 mm / #3 - #4
KEY FEATURES
Bidirectional stirrups, bars with bends, circles, and 2D and 3D shapes production
Zero scrap
100% usage of the bar length, generating no waste
The “random” function allows to consume mixed pieces of different unknown length bars or left over waste bars coming directly from steel mills
Cutting unit with a universal blade shear suitable for cutting bars of any diameter, featuring 4 cutting profiles for extended durability
Automatic stock bar storage system
"TFS" (Track Feeding System) for precise control
Worktop design with a lower folding shelf
Stirrup collectors or conveyor belts
